Extended Series

Extended Series

Send Inquiry

Description
Technical diameters

Inquiry	Reference Type	Bore Diameter	O.D.	Flange	Open Bearing				Shielded Bearing
Inquiry	r(min)	Bore Diameter	O.D.	O.D.	Outer Width	Inner Width	Flange Width	Reference Type	Outer Width	Inner Width	Flange Width
	FRW0ZZ	1.191	3.967	5.156	0.1	1.588	2.38	0.33	FRW0	2.38	3.175	0.787
	FRW1ZZ	1.397	4.763	5.944	0.1	1.984	2.779	0.584	FRW1	2.779	3.571	0.787
	FRW1-4ZZ	1.984	6.35	7.518	0.1	2.38	3.175	0.584	FRW1-4	3.571	4.366	0.787
	FRW133ZZ	2.38	4.763	5.944	0.1	1.588	2.38	0.457	FRW133	2.38	3.175	0.787
	FRW1-5ZZ	2.38	7.938	9.119	0.15	2.779	3.571	0.584	FRW1-5	3.571	4.366	0.787
	FRW144ZZ	3.175	6.35	7.518	0.1	2.38	3.175	0.584	FRW144	2.779	3.571	0.787
	FRW2-5ZZ	3.175	7.938	9.119	0.1	2.779	3.571	0.584	FRW2-5	3.571	4.366	0.787
	FRW2-6ZZ	3.175	9.525	10.719	0.15	2.779	3.571	0.584	FRW2-6	3.571	4.366	0.787
	FRW2ZZ	3.175	9.525	11.176	0.3	3.967	4.763	0.762	FRW2	3.967	4.763	0.762
	FRW155ZZ	3.967	7.938	9.119	0.1	2.779	3.571	0.584	FRW155	3.175	3.967	0.914
	FRW156ZZ	4.763	7.938	9.119	0.1	2.779	3.571	0.584	FRW156	3.175	3.967	0.914
	FRW166ZZ	4.763	9.525	10.719	0.1	3.175	3.967	0.584	FRW166	3.175	3.967	0.787
	FRW3ZZ	4.763	12.7	14.351	0.3	3.967	4.763	1.067	FRW3	4.978	5.773	1.067
	FRW168ZZ	6.35	9.525	10.719	0.1	3.175	3.967	0.584	FRW168	3.175	3.967	0.889
	FRW188ZZ	6.35	12.7	13.894	0.15	3.175	3.967	0.584	FRW188	4.763	5.558	1.143
	FRW4ZZ	6.35	15.875	17.526	0.3	4.978	5.773	1.067	FRW4	4.978	5.773	1.067
	FRW1810ZZ	7.938	12.7	13.894	0.15	3.967	4.763	0.33	FRW1810	3.967	4.763	0.33
