69 Thin-wall Series

69 Thin-wall Series

69 Thin-wall Series

Send Inquiry
PDF
  • 69 Thin-wall Series
  • 69 Thin-wall Series
InquiryBearing NO.Shape Dimension Basic Load Rating(N) Weight
d(mm)d(inch)D(mm)D(inch)B(mm) B(inch)r min(mm) r min(inch)Dynamic( Cr)Static( Cor)(kg)
694 4 0.1575  11 0.4331  4 0.1575  0.1 0.0059  960 350 0.0017
695 5 0.1969  13 0.5118  4 0.1575  0.2 0.0079  1070 420 0.0023
696 6 0.2362  15 0.5906  5 0.1969  0.2 0.0079  1470 600 0.0036
697 7 0.2756  17 0.6693  5 0.1969  0.3 0.0118  1600 710 0.0050
698 8 0.3150  19 0.7480  6 0.2362  0.3 0.0118  2230 910 0.0076
699 9 0.3543  20 0.7874  6 0.2362  0.3 0.0118  2480 1090 0.0085
6900 10 0.3937  22 0.8661  6 0.2362  0.3 0.0118  2690 1270 0.0100
6901 12 0.4724  24 0.9449  6 0.2362  0.3 0.0118  2890 1460 0.0120
6902 15 0.5906  28 1.1024  7 0.2756  0.3 0.0118  4320 2250 0.0180
6903 17 0.6693  30 1.1811  7 0.2756  0.3 0.0118  4590 2550 0.0190
6904 20 0.7874  37 1.4567  9 0.3543  0.3 0.0118  6370 3680 0.0380
6905 25 0.9843  42 1.6535  9 0.3543  0.3 0.0118  6660 4180 0.0440
6906 30 1.1811  47 1.8504  9 0.3543  0.3 0.0118  7240 5010 0.0500
6907 35 1.3780  55 2.1654  10 0.3937  0.6 0.0236  10390 7160 0.7500
6908 40 1.5748  62 2.4409  12 0.4724  0.6 0.0236  13020 9200 0.1180
6909 45 1.7717  68 2.6772  12 0.4724  0.6 0.0236  13490 10130 0.1280
6910 50 1.9685  72 2.8346  12 0.4724  0.6 0.0236  13900 10990 0.1330
6911 55 2.1654  80 3.1496  13 0.5118  1 0.0394  14820 12690 0.1770
6912 60 2.3622  85 3.3465  13 0.5118  1 0.0394  15080 13480 0.1910
6913 65 2.5591  90 3.5433  13 0.5118  1 0.0394  19950 17490 0.2000
6914 70 2.7559  100 3.9370  16 0.6299  1 0.0394  25950 31850 0.3270
6915 75 2.9528  105 4.1339  16 0.6299  1 0.0394  26780 23560 0.3450
6916 80 3.1496  110 4.3307  16 0.6299  1 0.0394  27590 25280 0.3630
6917 85 3.3465  120 4.7244  18 0.7087  1.1 0.0433  31900 29700 0.5170
6918 90 3.5433  125 4.9213  18 0.7087  1.1 0.0433  32800 31500 0.5400
6919 95 3.7402  130 5.1181  18 0.7087  1.1 0.0433  33700 33300 0.5670
6920 100 3.9370  140 5.5118  20 0.7874  1.1 0.0433  39901 39135 0.7710
